PARAMETER

参数

VALUE

Model

型号

1002

1002-K

NTEP/OIML Accuracy class

精度

Non-Approved

Maximum no,of intervals(n)

分度值

1000

Rated capacity-R.C. (Emax)

量程

0.5,1,2,3,5Kg

8,10,15,20kg

Rated output-R.O.

额定输出

0.5 mv/v±10%

1.5±10%

Zero Balance

零点平衡

±0.4%

±0.2%

Zero return 30 minutes

零点恢复

±0.0500%

Total Error

总误差

±0.10%

Temp.effect on zero

零点温漂

N/A

Temp.effect on output

灵敏度温漂

N/A

Temperature range

可用温度范围

-10°C to + 40°C

Temperature range, safe

温度补偿范围

-20°C to + 70°C

Maximum safe central overload

安全载荷

150%

Ultimate overload

极限载荷

300%

Excitation, recommended

推荐激励电压

5VDC/AC

Excitation, maximum

最大激励电压

15V DC/AC

Input impedance

输入阻抗

350 ohm±50 ohm

1000 ohm±50 ohm

Output impedance

输出阻抗

350 ohm±50 ohm

1000 ohm±50 ohm

Insulation resistance

绝缘阻抗

>2000 M ohm

Cable length

线长

0.25m

Environmental protection

防护等级

IP66

Recommended torque

平台尺寸

200×200mm
